Pitch 4.2 mm
◆ Current rating up to 9A (with #18 AWG)
◆ Voltage rating: 600V AC, DC
◆ Insulation resistance: DC 500V 1000MΩ min.
◆ Dielectric strength: 1500V AC/minute
◆ Contact resistance: Initial value/10mΩ Max.
After environmental testing/20mΩ Max.
◆ Ambient temperature range: -40℃ ~ +105℃
(Including temperature rise)
◆ Voltage rating: 600V AC, DC
◆ Insulation resistance: DC 500V 1000MΩ min.
◆ Dielectric strength: 1500V AC/minute
◆ Contact resistance: Initial value/10mΩ Max.
After environmental testing/20mΩ Max.
◆ Ambient temperature range: -40℃ ~ +105℃
(Including temperature rise)
